About this mod
Substance Painter and NVTT presets to use in Fallout 4 mods.
- Requirements
- Permissions and credits
In the downloads section you will find 2 files:
1. A Substance Painter Library:
2. A zip file of presets to be used with Nvidia Texture Tools Exporter.
Step 1:
download "Substance Painter Export Preset for Fallout 4", then mount as a Substance Painter Library
Step 2:
Export the textures using the export preset in Substance Painter. You will need to populate the Base Color, Normal+Height+Mesh, and Roughness to properly export.
Step 3:
Open Nvidia Texture Tools Exporter, open each EXR file and export with the appropriate preset. Export as .DDS file.
1. A Substance Painter Library:
- Contains an export preset to properly export Fallout 4 textures from Substance Painter. This preset is used with the "pbr-metal-rough-with-alpha-blending" shader. will export with the prefix _n, _d, _s in 32 bit Float EXR.
2. A zip file of presets to be used with Nvidia Texture Tools Exporter.
- Fallout 4 HDR Normal Map.dpf (BC6U HDR RGB 8 bpp unsigned)
- Fallout 4 RGBA w Alpha.dpf (BC7 RGBA 8bpp)
- Resize DDS Texture 50 Percent.dpf (BC7 RGBA 8bpp)
Step 1:
download "Substance Painter Export Preset for Fallout 4", then mount as a Substance Painter Library
Step 2:
Export the textures using the export preset in Substance Painter. You will need to populate the Base Color, Normal+Height+Mesh, and Roughness to properly export.
Step 3:
Open Nvidia Texture Tools Exporter, open each EXR file and export with the appropriate preset. Export as .DDS file.
